5094-IB32,5094数字32输入24 vdc

5094-IB32 and 5094-IB32XT Digital 32-point Sinking Input Modules

This figure shows a wiring diagram for the 5094-IB32 and 5094-IB32XT modules. You must connect a 24V DC power source to the left SA+/–

terminals to provide field-side power.

5094-IB32 and 5094-IB32XT Wiring Diagram。
