5094-OB16，5094数字16输出

5094-OB16 and 5094-OB16XT Digital 16-point Sourcing Output Modules

This figure shows a wiring diagram for the 5094-OB16 and 5094-OB16XT modules. You must connect a 24V DC power source to the left SA+/–

terminals to provide field-side power.

5094-OB16 and 5094-OB16XT Wiring Diagram。
