5094-IF8，5094模拟8输入
5094-IF8 and 5094-IF8XT Analog 8-channel Current/Voltage Input Modules
This figure shows a wiring diagram for the 5094-IF8 and 5094-IF8XT modules when used in current mode. You must connect a 24V DC power
source to the left SA+/– terminals to provide field-side power.
5094-IF8 and 5094-IF8XT Wiring Diagram — 2-wire and 3-wire Current Mode。
